**3X-UI** — advanced, open-source web-based control panel designed for managing Xray-core server. It offers a user-friendly interface for configuring and monitoring various VPN and proxy protocols.
> [!IMPORTANT]
> This project is only for personal usage, please do not use it for illegal purposes, and please do not use it in a production environment.
As an enhanced fork of the original X-UI project, 3X-UI provides improved stability, broader protocol support, and additional features.
## TrustTunnel Support
This fork adds support for [TrustTunnel](https://github.com/TrustTunnel/TrustTunnel) — a fast VPN protocol by AdGuard, written in Rust. TrustTunnel runs as a separate process alongside Xray and can be managed through the same panel UI.
### How it works
- TrustTunnel appears as a protocol option (`trusttunnel`) when creating a new inbound
- Each TrustTunnel inbound runs its own process independently of Xray
- Supports multiple clients with username/password authentication
- Supports HTTP/1.1, HTTP/2, and QUIC (HTTP/3) transports
- Uses its own TLS certificates (configured per inbound)
### Installation
1. Install the TrustTunnel binary:
```bash
curl -fsSL https://raw.githubusercontent.com/TrustTunnel/TrustTunnel/refs/heads/master/scripts/install.sh | sh -s --
```
2. Install/update 3x-ui as usual (the panel will auto-detect the TrustTunnel binary)
3. In the panel, create a new inbound and select `trusttunnel` as the protocol
### Configuration
When creating a TrustTunnel inbound, you need to specify:
| Field | Description |
|-------|-------------|
| **Port** | Listen port (e.g., 443) |
| **Hostname** | Domain name for TLS SNI matching |
| **Certificate Path** | Path to TLS certificate chain (PEM) |
| **Private Key Path** | Path to TLS private key (PEM) |
| **Transport Protocols** | Enable/disable HTTP/1.1, HTTP/2, QUIC |
| **Clients** | Username/password pairs for authentication |
### Upgrading 3x-ui
TrustTunnel integration is designed for minimal merge conflicts:
- **3 new files** are fully isolated (`trusttunnel/process.go`, `web/service/trusttunnel.go`, `web/html/form/protocol/trusttunnel.html`)
- Changes to existing files are small and clearly marked
- No database schema changes — settings are stored as JSON in the existing `Settings` field
## Quick Start
```bash
bash <(curl -Ls https://raw.githubusercontent.com/mhsanaei/3x-ui/master/install.sh)
```
For full documentation, please visit the [project Wiki](https://github.com/MHSanaei/3x-ui/wiki).
## A Special Thanks to
- [alireza0](https://github.com/alireza0/)
## Acknowledgment
- [Iran v2ray rules](https://github.com/chocolate4u/Iran-v2ray-rules) (License: **GPL-3.0**): _Enhanced v2ray/xray and v2ray/xray-clients routing rules with built-in Iranian domains and a focus on security and adblocking._
- [Russia v2ray rules](https://github.com/runetfreedom/russia-v2ray-rules-dat) (License: **GPL-3.0**): _This repository contains automatically updated V2Ray routing rules based on data on blocked domains and addresses in Russia._
## Support project
**If this project is helpful to you, you may wish to give it a**:star2:
