**3X-UI** — advanced, open-source web-based control panel designed for managing Xray-core server. It offers a user-friendly interface for configuring and monitoring various VPN and proxy protocols.
> [!IMPORTANT]
> This project is only for personal usage, please do not use it for illegal purposes, and please do not use it in a production environment.
As an enhanced fork of the original X-UI project, 3X-UI provides improved stability, broader protocol support, and additional features.
## Quick Start
```bash
bash <(curl -Ls https://raw.githubusercontent.com/mhsanaei/3x-ui/master/install.sh)
```
For full documentation, please visit the [project Wiki](https://github.com/MHSanaei/3x-ui/wiki).
## Database Backends
3X-UI supports both `SQLite` and `PostgreSQL` as interchangeable backends. All application logic is written against [GORM](https://gorm.io/) — Go's database-agnostic ORM — so queries work identically on either engine. You can switch backends at any time through the panel UI without data loss.
### Choosing a Backend
| | SQLite | PostgreSQL |
|---|---|---|
| Setup | Zero config, file-based | Requires a running PG server |
| Best for | Single-node, low traffic | Multi-node, high concurrency |
| Backups | Portable + native file export | Portable export |
### Switching Backends (Panel UI)
1. Open **Settings → General → Database**.
2. Select a backend (`SQLite` or `PostgreSQL`) and fill in connection details.
3. Click **Test Connection** to verify.
4. Click **Switch Database** — the panel will:
- Save a portable backup of current data automatically.
- Migrate all data to the new backend.
- Restart itself.
> The target database must be empty before switching. Use **Test Connection** before switching to catch misconfigurations early.
### Local PostgreSQL (panel-managed)
When selecting **Local (panel-managed)** mode, the panel installs and manages PostgreSQL automatically (Linux, root only):
```bash
# The panel uses postgres-manager.sh internally.
# No manual PostgreSQL setup required.
```
### External PostgreSQL
Point the panel at any existing PostgreSQL 13+ server:
1. Create a dedicated database and user.
2. Enter the connection details in Settings → Database.
3. Use **Test Connection**, then **Switch Database**.
### Environment Variable Override
For Docker and infrastructure-as-code deployments, set these environment variables to control the backend without touching the UI:
```bash
XUI_DB_DRIVER=postgres # or: sqlite
XUI_DB_HOST=127.0.0.1
XUI_DB_PORT=5432
XUI_DB_NAME=x-ui
XUI_DB_USER=x-ui
XUI_DB_PASSWORD=change-me
XUI_DB_SSLMODE=disable # or: require, verify-ca, verify-full
XUI_DB_MODE=external # or: local
XUI_DB_PATH=/etc/x-ui/db/x-ui.db # SQLite only
```
When any `XUI_DB_*` variable is set, the Database section in the panel UI becomes read-only.
### Backup & Restore
| Format | Works with | When to use |
|---|---|---|
| **Portable** (`.xui-backup`) | SQLite + PostgreSQL | Switching backends, Telegram bot backups, long-term storage |
| **Native SQLite** (`.db`) | SQLite only | Quick raw file backup while on SQLite |
- The Telegram bot sends a **portable backup** automatically — this works regardless of which backend is active.
- Portable backups can be imported back on either SQLite or PostgreSQL.
- Legacy `.db` files from older 3x-ui versions can be imported even while PostgreSQL is active.
